The VIAIR Interstate Constant Duty OBA operates at 200PSI from a 1.5-gallon tank and it's powered by a 480C Chrome compressor, making for fast inflation rates for most Class A Motorhome tires from 90 to 100 PSI in under 3 minutes. This pre-packaged air solution comes with all the necessary components needed to install a working system, useful for multiple pneumatic applications such as air tools, air lockers, blowing and cleaning tasks, inflating recreational equipment, air horns, and many others.
Features:
- 480C Chrome VIAIR Compressor w/ Thermal Overload Protector
- 1.5 Gallon Matte Black VIAIR Air Tank (200 PSI)
- Illuminated Dash Panel Gauge Kit, Black Face 200 PSI
- Sealed Pressure Switch (165 PSI on, 200 PSI off)
- 40-Amp Sealed 4-Prong Relay w/ Pre-wired Female Socket
- Mini ANL Fuse holder w/ 40-Amp Fuse
- Digital RV Tire Inflation Gun w/ 180PSI Gauge
- (2) 30 ft. Inside Braided Black Coil Hose w/ Quick Connect & stud
- 90° Twist-on 40" Chuck Air Hose
- 45° Dually Extended Reach Chuck
- Rubber-Tipped Blow Gun
- RV Winterization Kit
- 1/4" (M) to 1/8" (M) NPT Reducer
- 3/8" (F) to 1/4" (M) NPT Reducer
- 1/4" NPT Plug Kit
- 5 Pc. Tank Port Fittings Kit (For 200 PSI Rated Systems
- Air Source Relocation Kit
- VIAIR Storage Bag
Specifications:
- 12-Volt
- Permanent Magnetic Motor
- Duty Cycle: 100% @ 100 PSI (50% @ 200 PSI)
- Max. Working Pressure: 200 PSI
- Max. 12V Amp Draw: 23-Amps
- Ingress Protection Rating: IP67
Manual: CLICK HERE
Note: Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque for 1/8" is 10 ~ 11 ft. lbs. Recommended torque for 1/4" and 3/8" is 16 ~ 18 ft. lbs.
Other Part Numbers:
Viair #VIA50019
⚠ WARNING:
Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov
