The Base Camp Heavy Duty OBA by VIAIR operates at 150PSI from a 2-gallon tank and it's powered by a 400C Chrome compressor, making for fast inflation rates for most Class C RV Tires from 70 to 80 PSI in approximately one minute. This pre-packaged air solution comes with all the necessary components needed to install a working system, useful for multiple pneumatic applications such as air tools, air lockers, blowing and cleaning tasks, inflating recreational equipment, air horns, and many others.
Features:
- 400C Chrome VIAIR Compressor w/ Thermal Overload Protector
- 2 Gallon Matte Black VIAIR Air Tank (150 PSI)
- Illuminated Dash Panel Gauge Kit, Black Face 150 PSI
- 40-Amp Sealed 4-Prong Relay w/ Pre-wired Female Socket
- Sealed Pressure Switch (110 PSI on, 145 PSI off)
- Mini ANL Fuse holder with 40-Amp Fuse
- Digital RV Tire Inflation Gun w/ 180 PSI Gauge
- (2) 30 ft. Inside Braided Black Coil Hose w/ Quick Connect & stud
- 90° Twist-on 40" Chuck Air Hose
- 45° Dually Extended Reach Chuck
- Rubber-Tipped Blow Gun
- Air Source Relocation Kit
- 1/4" (M) to 1/4" (M) NPT Reducer
- 5 Pc. Tank Port Fittings Kit (For 150 PSI Rated Systems)
- VIAIR Storage Bag
Specifications:
- 12-Volt
- Permanent Magnetic Motor
- Duty Cycle: 33% @ 100 PSI
- Max. Working Pressure: 150 PSI
- Max. 12V Amp Draw: 30-Amps
- Ingress Protection Rating: IP67
Recommended Components:
- RV Winterization Kit (P/N 90145)
Manual: CLICK HERE
Note: Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque for 1/8" is 10 ~ 11 ft. lbs. Recommended torque for 1/4" and 3/8" is 16 ~ 18 ft. lbs.
Other Part Numbers:
Viair #VIA50017
