Rockford Fosgate Punch 10" 300-Watt Powered Truck Enclosure - P300-10T
Rockford Fosgate Punch 10" 300-Watt Powered Truck Enclosure - P300-10T - Image 4 Rockford Fosgate Punch 10" 300-Watt Powered Truck Enclosure - P300-10T - Image 2 Rockford Fosgate Punch 10" 300-Watt Powered Truck Enclosure - P300-10T - Image 3 Rockford Fosgate Punch 10" 300-Watt Powered Truck Enclosure - P300-10T - Image 4
The Punch P300-10T is a universal "all in one" solution for dropping Bass in any factory or aftermarket system. This model features a 10" high output woofer with a 300-watt internal amplifier in a slim design enclosure that's great for universal truck applications. The enclosure features quick release input and power connectors for easy removal when extra space is required.

The Punch 300-10T is a self-contained subwoofer enclosure with built-in amplifier. This "all in one" solution is great for systems that need extra Punch on the low-end of the frequency spectrum. The 10" high output subwoofer is impedance optimized for the built in 300-watt class-D amplifier that features a low-pass crossover, bass EQ and phase switch. The enclosure can be connected via speaker level inputs for connection to factory systems, or traditional line level inputs for aftermarket systems. It also features an intelligent auto turn-on/off circuit that eliminates the need for a separate turn-on wire. The enclosure itself is precision designed and constructed using MDF (Medium Density Fiberboard) for the best acoustical properties and covered with heat activated vinyl finish to resist marks.

Features:
  • High-Efficiency, Low Current Amplifier Design
  • Optimized 10" Low Impedance Woofer
  • 300 Watt Class-D Amplifier with Optimized "Closed Loop" Design
  • Adjustable 12db/Octave low pass crossover
  • On Board Phase Switch
  • Intelligent auto turn on/off function
  • Robust Power/Ground connections
  • Quick Input Connections for Easy Removal
  • On Board Adjustable Bass EQ
  • Remote bass level control included
  • Separate low level and speaker level inputs
  • Precision Constructed MDF Enclosure with Heat Activated Vinyl Finish
  • Thermal and over/under voltage protection
  • Slim Design For Truck Applications
  • 1 year Warranty
Specifications:
  • Woofer Quantity: 1
  • Woofer Size: 10"
  • Woofer Series: Proprietary
  • Frequency Response: 25 Hz to 200 Hz
  • Power Handling (Watts RMS): 300 Watts RMS
  • Enclosure Type: Sealed
  • Enclosure Material: 5/8" MDF (Medium Density Fiberboard
  • Integrated Amplifier: 300 Watts RMS
  • Crossover Controls:
    • Variable 50 Hz to 200 Hz
    • 12dB/Octave Butterworth
  • Tone Controls:
    • Bass Boost
    • 0 dB to +12 dB;
  • Phase Control: 0° to 180°
  • Remote Control:
    • Punch Level Control (Included)
    • Replacement Part: 1130-59232-01
  • Auto Turn-On Selector:
    • Remote Trigger
    • DC Offset Sense
    • Audio Sense
  • Input Switch:
    • High-Level (Speaker Line)
    • Low-Level (RCA)
  • Signal Input:
    • Low/High-Level: 1 RCA Pair (L/R Summed)
    • Replacement Part: 1130-59232-01
  • Input Sensitivity:
    • Low-Level: 150 mV to 6 V
    • High-Level: 300 mV to 12 V
  • Input Impedance: 20k Ohms
  • Power Input Connector:
    • Quick Disconnect
    • Replacement Part: 1130-59232-01
  • Power Wire Gauge:
    • B+/GND: 8 AWG
    • REM: 18 AWG
  • Circuit Topology Class: Class-D
  • Heatsink Type: Extruded Aluminum
  • Cooling: Convection
  • Visual Indicators: Power/Protect LED
  • Fuses: 20 Amp (2 x 10 Amp ATO Fuse)
  • Dimensions Wedge H x W x D1 x D2:
    • 13.3" x 21.7" x 4.8" x 7.9"
    • 338 mm x 552 mm x 122 mm x 201 mm
  • Shipping Weight: 25 lbs. (11.3 kg)
Proposition 65

⚠ WARNING: Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov

Since day one, Rockford Fosgate® spearheaded the car audio revolution. Nothing's changed. Rockford Fosgate is still the global leader in audio innovation, design and engineering, delivering an experience of passion through sound to drivers, boaters, motorcyclists and off-road enthusiasts.
Rockford Corporation offers a limited warranty on Rockford Fosgate products:

Length of Warranty
  • All Speakers – 1 Year
  • Signal Processors – 1 Year
  • PRIME Amplifiers – 1 Year
  • PUNCH Amplifiers – 1 Year
  • POWER Amplifiers – 2 Years
  • Any Factory Refurbished Product – 90 days (receipt required)
What is Covered

This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate Dealers in the United States of America or its possessions. Product purchased by consumers from an Authorized Rockford Fosgate Dealer in another country are covered only by that country's Distributor and not by Rockford Corporation.

Who is Covered

This warranty covers only the original purchaser of Rockford product purchased from an Authorized Rockford Fosgate Dealer in the United States. In order to receive service, the purchaser must provide Rockford with a copy of the receipt stating the customer name, dealer name, product purchased and date of purchase. Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be equivalent) at Rockford's discretion.

What is Not Covered

1. Damage caused by accident, abuse, improper operations, water, theft
2. Any cost or expense related to the removal or reinstallation of product
3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center
4. Any product which has had the serial number defaced, altered, or removed
5. Subsequent damage to other components
6. Any product purchased outside the U.S.
7. Any product not purchased from an Authorized Rockford Fosgate Dealer

Limit on Implied Warranties

Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the period of the express warranty set forth above. Some states do not allow limitations on the length of an implied warranty, so this limitation may not apply. No person is authorized to assume for Rockford Fosgate any other liability in connection with the sale of the product.

How to Obtain Service

Please call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.

EU Warranty

This product meets the current EU warranty requirements, see your Authorized dealer for details.

Warranty Outside the USA

The above warranty information is for residents located within the United States of America. For warranty and service information outside the USA, please select the Authorized World Wide Distributor for your country as details vary by country.
