Radium Engineering F90000267 Fuel Hanger for Acura Integra & Honda Civic

Say goodbye to your stock fuel pump assembly and say hello to the Radium Engineering F90000267 fuel hanger! Designed specifically for the Acura Integra (1994-2001) and Honda Civic (1992-2000), this fuel hanger offers a seamless drop-in installation that requires no cutting or modifying of your vehicle’s sheet metal or fuel tank. It's all about making your life easier while ensuring your car runs smoothly.

Fuel Pump Placement

The fuel pump is cleverly positioned in the factory collector bowl, providing you with peace of mind against fuel starvation. This means you can push your vehicle's limits without worrying about running dry.

Outlet Fittings

When it comes to versatility, the fuel pump outlet is tapped for 8AN ORB (3/4"-16) female threads on the top plate. You’ll find multiple adapter fittings included:

• The preinstalled -6AN male fitting allows for an aftermarket feed line.
• The 8.5mm barbed adapter fitting lets you reuse the OEM feed line from the 94-95 Integra or 92-95 Civic.
• The SAE quick connect fitting is perfect for reusing the OEM feed line from the 96-01 Integra or 96-00 Civic.

Return Port Fittings

For the return port, you'll get two handy fittings:

• A preinstalled 6.5mm barbed fitting that allows you to reuse the OEM return line. Just a heads up: for the 96-01 Integra and 96-00 Civic, you’ll need to extend the OEM return hose.
• A -6AN male fitting for those opting for an aftermarket return line.

Compatibility and Features

All fittings are machined low enough to ensure they won't interfere with the fuel pump access cover. This setup is compatible with various fuel pumps, specifically designed for part numbers 20-0790-00 and 20-0792-00, allowing you to use one aftermarket fuel pump.

Electrical Connections

The custom-designed stainless steel electrical studs are a game changer. They easily handle the high current demand that compact multi-pin bulkhead connectors struggle with. Plus, these serviceable connections are hermetically sealed and resistant to all standard and exotic fuels. You’ll also receive non-conductive anodized aluminum acorn nuts to prevent any accidental short circuits. And don’t worry about wear and tear; the in-tank wiring is insulated with high-quality, chemically resistant ETFE.

Key Features

• Drop-In Installation
• Anodized Aluminum Construction
• Merged 8AN ORB Female Pump-Out Port
• Fittings for Aftermarket and OEM Lines
• Capable of Supporting 2 Pumps with Add-On
• Compatible with Various Pumps
• Included Fuel Pump Filter Sock
• High Current Electrical Hardware
• Durable Stainless Steel Hardware and Clamps
• Gasoline, Methanol, and E85 Compliant

Fitment

• Acura Integra 1994-2001
• Honda Civic 1992-2000

Important Notes

• If you're installing a Single Walbro GSS342 (255LPH) fuel pump, you can reuse the OEM fuel pump wiring.
• For optimal performance, it’s recommended to upgrade the OEM wiring to ensure the pumps are receiving full power.
• Universal fuel pump wiring kits can be found HERE. Make sure to select one for each aftermarket pump.
• If you need two aftermarket pumps, don’t forget to grab the supplementary "dual pump add-on." Choosing the right fuel pump(s) depends on your expected engine power output, fuel type (gasoline, E85, etc.), and fuel pressure.
