ICON 2021-2023 Ford Bronco Rear 1.25-3.5" Lift 2.5 VS RR Coilover Kit CLEARANCE
$1697.81
ICON Vehicle Dynamics V.S. 2.5 Series remote reservoir rear coilover shocks are an incredible upgrade for the rear end of the 2021-UP Ford Bronco. These adjustable coilovers allow up to 2-3" of rear lift height adjustability on 4-door Broncos without the Sasquatch package or 1.25-2.25" of rear lift over stock 4-door Sasquatch equipped Broncos, allowing the use of larger, more aggressive wheel and tire combinations. ICON's Vehicle-specific shock length and valving along with the larger 2.5" shock body and increased piston area over stock components yield the maximum travel possible along with superior ride quality and suspension performance both on- and off-road. Reservoirs greatly increase shock oil volume and heat dissipation surface area to resist overheating and cavitation under hard use, which can lead to damper fade. These rear coilovers are mounted in a shaft up orientation and feature unique ICON engineered progressive triple rate coil springs, allowing for softer spring rate at ride height that ramps up as the coil compresses for improved bottom out resistance. This shaft up orientation also requires the reservoir hose to be routed along the rear lower links so ICON offers hose bracket options for the OE or ICON tubular links while ICON billet links incorporate this bracketry into their design. When paired with ICON 2.5 Series front coilovers vehicle control will be balanced front to rear, resulting in the best overall driving experience for your Ford Bronco.

View Installation Instructions

Features:
  • Increased wheel travel (up to 14") and ride quality over stock
  • Vehicle specific tuned for superior shock damping and control
  • Remote reservoirs maintain cooler operating temperatures during extended off-road use
  • Adjustable up to 2-3" of rear lift height on non-Sasquatch or 1.25-2.25" of rear lift on Sasquatch Broncos
  • Unique ICON engineered triple rate coil springs
  • 6061 Aircraft grade aluminum CNC machined components
  • Corrosion resistant CAD plated shock bodies with 7/8" diameter shaft
  • FK rod end bearings for extended longevity and minimal deflection
  • Fully rebuildable and re-tunable
  • 100% Bolt-on - no drilling, cutting or welding necessary for installation
Specifications:
  • Add-On Part: 198000 - 2 PIN COILOVER SPANNER WRENCH KIT
  • Add-On Part: 198001 - BILLET SPANNER WRENCH KIT
  • Add-On Part: 252012 - -4 TO -10 HOSE SHIELD KIT
  • Add-On Part: 611072 - 21-UP BRONCO HOSE ROUTE KIT OEM REAR LINK 1.9"
  • Add-On Part: 611073 - 21-UP BRONCO HOSE ROUTE KIT REAR LINK 1.75"
  • Add-On Part: 611074 - C/O BUMP STOP SPACER KIT 7/8" SHAFT 3/8" TALL
  • Adjustable Damping: NO
  • Adjustable Height: Yes
  • Body Diameter: 2.5 IN
  • Boot Included: No
  • Coil Over Springs Included: Yes
  • Damping Type: Oil
  • Dust Shield: No
  • Gas Charged: Yes
  • Grade Type: Performance
  • Lower Mount Type: Eyelet
  • Material: Aluminum
  • Material: Steel
  • Maximum Lift: 3 IN
  • OEM Wheels & Tires Fitment: Yes
  • Recommended Aftermarket Tires: (With Sasquatch Package): 35" x 12.50" (37" tires require coilover bump stop spacers)
  • Recommended Aftermarket Tires: (Without Sasquatch Package): 35" x 12.50" (37" tires require coilover bump stop spacers)
  • Recommended Aftermarket Wheels: (With Sasquatch Package): ICON Alloys | 17x8.5" w/ 4.75" Backspace / 0mm Offset
  • Recommended Aftermarket Wheels: (With Sasquatch Package): ICON Alloys | 18x9" w/ 5.00" Backspace / 0mm Offset
  • Recommended Aftermarket Wheels: (With Sasquatch Package): ICON Alloys | 20x9" w/ 5.00" Backspace / 0mm Offset
  • Recommended Aftermarket Wheels: (Without Sasquatch Package): ICON Alloys | 17x8.5" w/ 5.75" Backspace / 25mm Offset
  • Remote Reservoir: Yes
  • Service Parts: 252011 - 2.5 PIGGYBACK/REMOTE RESI/BYPASS REBUILD KIT
  • Shaft Diameter: 0.875 IN
  • Shock Absorber Body End Measuring Point: CENTER OF EYELET
  • Shock Absorber Rod End Measuring Point: Top of Mounting Plate
  • Spring Color: Black
  • Spring Material: Steel
  • Spring Rate Type: Progressive Triple Rate
  • Upper Mount Type: Mounting Plate
Notes:
  • When Running 37" Tires Use Up Travel Limiter'S Part #611074 For The Rear
  • When Running Icon Tubular Lower Links Use Part #611073
  • When Running Factory Lower Links Use Part #611072
  • Oem Wheels & Tires Fitment: Yes
  • Lift Height Ranges Advertised Are For 4-Door Models. 2-Door Models Will Net Approximately .5" Of Additional Rear Lift Over Stock.
  • Not Compatible With Bronco Raptor
  • Triple Rate Rear Coils Are Optimized For Improved Suspension Performance And Ride Quality For A Near-Stock Weight Bronco. Their Softer Initial Spring Rates Will Net Lower Than Advertised Ride Heights As Weight Is Added To The Rear Of The Vehicle. Coil Spring Options For Heavier Equipped Broncos Coming Soon!
Fitment:
  • Ford Bronco Base 4 2021-2023
  • Ford Bronco Wildtrak 4 2021-2023
  • Ford Bronco Wildtrak 2 2021-2023
  • Ford Bronco Base 2 2021-2023
  • Ford Bronco Big Bend 4 2021-2023
  • Ford Bronco Big Bend 2 2021-2023
  • Ford Bronco Black Diamond 4 2021-2023
  • Ford Bronco Black Diamond 2 2021-2023
  • Ford Bronco Outer Banks 4 2021-2023
  • Ford Bronco Outer Banks 2 2021-2023
  • Ford Bronco Badlands 4 2021-2023
  • Ford Bronco Badlands 2 2021-2023
  • Ford Bronco First Edition 4 2021-2021
  • Ford Bronco First Edition 2 2021-2021
  • Ford Bronco Everglades 2022-2022

Other Part Numbers:
Icon Vehicle Dynamics #154952213

Proposition 65

WARNING: Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov

Vehicle
2021-2023
Ford Bronco

Icon Vehicle Dynamics Logo

ICON Lift Kits

Offroading is a great way to explore new areas and terrains, pushing yourself and your vehicle to the limit in pursuit of a new and exciting adventure. ICON Vehicle Dynamics is widely known as one of the best lift kit manufacturers currently on the market, with ICON lift kits offering offroading experts everything they need to attack any terrain. Vivid Racing offers ICON suspension lift kits for a variety of different truck makes and models, as well as other ICON auto parts.

What is ICON Vehicle Dynamics?

ICON Vehicle Dynamics is a premier suspension manufacturer that specializes in bolt-on performance suspension components and shock absorbers for Jeeps, SUVs, and trucks. Led by chief engineer and SCORE champion driver Dylan Evans, ICON Vehicle Dynamics encompasses the unique qualities it needs to design and build the best suspension parts and test them in real-world applications and race conditions. The company is customer-driver, technology-oriented, and focused on world-class engineering processes. ICON Vehicle Dynamics is a SEMA member and the premier supplier of suspension parts to leading vehicle brands like Toyota, Nissan, Jeep, Ford, GM, and Dodge.

What Sets ICON Lift Kits and ICON Auto Parts Apart From the Competition?

ICON Vehicle Dynamics is capable of developing such revolutionary performance suspension systems because of its specially trained staff. Its engineers actually start out by finding the desired outcome for a vehicle they are working on. By researching and studying forces and their effect on the car in motion, they are also to figure out what improvements can be made in terms of drivability and handling characteristics. The result is the fabrication of some of the highest quality and best performing suspension parts on the market.

What also sets ICON auto parts apart from the competition is the brand's astonishing commitment to excellence and dedication to ride development and testing. When you combine the company's vehicle dynamic theory with its extensive experience and involvement in off-road racing and rock crawling, there isn't much they cannot do. The engineers over at ICON Vehicle Dynamics take pride in being in control of everything that goes on and the driving force behind every part that comes off the production line. All of this is made possible by laser cutting, CNC machining, metal forming, and welding and assembly, which is all done in house with careful attention to detail. It's no wonder ICON Vehicle Dynamics has earned itself such a solid reputation based on performance, quality, and service when it comes to performance suspension systems.

What Are the Benefits of Installing ICON Lift Kits?

ICON lift kits are known as some of the best lift kits currently available on the market, helping trucks, SUVs and Jeeps master any trail, regardless of the terrain. So what are the benefits of purchasing and installing an ICON suspension lift kit?

Perfectly Customized to Your Vehicle

ICON lift kits are not one size fits all. ICON suspension lift kits are specifically designed for the make and model of your vehicle, giving you the clearance you need to become an offroad expert.

100% Bolt-On System

ICON auto parts always aim to make installation as simple and straightforward as possible. That is why all ICON lift kits use a 100% bolt-on system, meaning that installation will not require any cutting, drilling, or welding.

Incredible Ride Quality

With an ICON suspension lift kit, your stock springs will be completely isolated, ensuring a smooth and safe ride.

Avoid Body Rolls

ICON lift kits do everything possible to avoid a truck body roll, keeping you and your passengers safe. After installing one of our lift kits, you actually have less of a chance of undergoing a body roll than a stock truck.

Durable Design Using High-Quality Products

We only use high-quality parts and products for ICON lift kits in order to ensure that the lift kit will be both durable and longlasting. If you are an offroad enthusiast, you depend on your lift kit to help you tackle unruly terrain, and we never want your ICON lift kit to let you down.

Upgrade to ICON Vehicle Dynamics Today

If you have been longing to switch up your car's suspension, then look no further. ICON Vehicle Dynamics has all the best suspension components and systems to upgrade your vehicle's overall stance, appearance, and ride quality. Vivid Racing is proud to carry a wide array of ICON products like coilover springs, driveshafts, handling arms, bushings, leaf springs, shocks, lift kits, steering components, and much, much more! If you are having trouble finding a specific part above, give our sales team a call at (480) 966-3040.

Lifetime warranty on all components, springs, and weldments. Shock warranty is limited to manufacture defect for 12 months from the date of purchase. The ICON Delta Joint features a 5 year warranty.

Installation Instructions

Click to view the Installation Instructions here
