All-in-One Performance Kit

Are you on the hunt for a comprehensive kit that truly has it all? Look no further! This amazing kit features a mandrel-bent 4.5-inch LBZ style intake tube designed to boost airflow significantly. Plus, with HSP's signature heat shield box, you can say goodbye to unwanted hot air sneaking into your cold air intake. Just a 1-degree increase in intake air temperature can lead to a 3hp loss, so keeping things cool is crucial!

Turbo Mouthpiece & PCV System

One of the standout features of this kit is HSP's high flow turbo mouthpiece. It allows you to reroute your factory PCV system and remove the factory resonator box, preventing engine oil from gumming up your turbo and intake system (PCV re-route sold separately, see 003-1-HSP). You’ll also receive our 3-inch mandrel-bent hot side and cold side tubes, along with a user-friendly two-piece Y-bridge that comes equipped with race-proven 5-layer silicone boots. This ensures a snug fit that you can rely on.

Hot Side Intercooler Tube Solution

The factory hot side intercooler tube measures only 2.25 inches in diameter and has a 90-degree boot at the intercooler that is known to fail. Our design eliminates the risk of the hot side intercooler tube rubbing against the power steering line, which can cause a boost leak. By routing the hot side tube directly into the intercooler, we achieve lower temperatures, improved airflow, and extra clearance in those tight spots.

Cold Side Tube & Exhaust Efficiency

Our 3-inch cold side tube guarantees that your engine receives all the air it craves. The bolted-together two-piece Y-bridge simplifies installation and ensures a leak-free seal, keeping you off the side of the road. To help your engine expel exhaust gases efficiently, we’ve included factory replacement 2-inch up pipes made with .120 inch wall tubing and the toughest bellows available, ensuring they last as long as your truck.

Stylish Upgrades

When it comes to aesthetics, we’ve included a forward-facing thermostat housing with a coolant return to keep your VGT turbo cool. Is your factory coolant tank looking a bit worn? No worries! We’ve also added a factory replacement coolant tank that features an all-aluminum design and an integrated low coolant sensor, keeping your engine bay looking sharp.

Included Components

• 2x 3 inch x 4 inch Straight Boot
• 5x 3 inch T-Bolt Clamps
• 1x 2.25 inch - 3 inch Reducer Boot
• 1x 2.25 inch T-bolt Clamp
• 1x Bridge Neck O-Ring
• 2x Bridge Neck Stud
• 2x Bridge neck 12-Point Nut
• 2x 5/8 inch Worm Gear clamps
• 1x 1/8 inch NPT Brass Plug
• 2x M4 x .7x10mm Bolt
• 3x 10-32 x 3/8 inch Button Head Screw
• 4x 1/8 inch Aluminum Rivet
• 1x 4 inch - 4.5 inch Reducer Boot
• 1x 4 inch T-Bolt Clamp
• 1x 4.5 inch T-bolt Clamp
• 1x 4.5 inch Filter
• 1x Turbo Inlet O-ring
• 1x Radiator Cap
• 5x 1/2 inch Worm Gear Clamps
• 1x 1 inch Worm Gear Clamp
• 1x 1/2 inch NPT Float Switch
• 1x Low coolant sensor
• 1x Thermostat Housing O-ring
• 3x M6x1.0x35mm Flange Bolts
• 6x M6 Fender Washers
• 3x M6 Nylon Lock Nut
• 4x M8x1.25-25mm Socket Cap Bolt
• 4x M8x1.0-18mm Socket Cap Bolt
• 1x M14x1.5 to 3/8 inch Hose Barb
• 1x M14x1.5 Metric Port Plug
• 1x Metric Bonded Seal 14mm
• 1x 1.75 inch x 3 inch Straight Boot
• 1x 1.75 inch 90 degree Boot
• 2x Up-Pipe Gasket (Turbo Side)
• 2x Up-Pipe Gasket (Manifold Side)
• 4x 1 3/4 inch Worm Gear Clamps
• 16 inch of Trim seal
• 1 1/2' of 3/8 inch heater hose

Compatibility

Compatible with LLY: 04.5-05 VIN Code 2.

If you're wondering how to find your VIN code, just check the 8th character of your VIN number—this will tell you the engine code. The 10th character indicates the year of your truck.
