This is the ultimate in high performance Race proven off-road suspension. This system will give you up to 18" of travel with a massive 1.5" lower mono balls and 1" uppers; just like the Trophy Trucks. The lower pivots are not urethane, or Delrin they are massive 1" mono balls. This kit is high end so if you are looking for the best off-road system for your A-Arm Ranger you have found it.
The race kit uses our Camburg 2.25 front hubs along with Wilwood 12" rotors and their 4 piston superlite calipers. With the bigger hubs you'll need a wheel that has a 5 on 5.5" bolt pattern with a 4.25" center-bore for 5/8" wheel studs.
This kit is for the serious racer and requires extensive fabrication. We recommend a qualified off-road race shop to install and setup this suspension system.
What's Included:
The race kit uses our Camburg 2.25 front hubs along with Wilwood 12" rotors and their 4 piston superlite calipers. With the bigger hubs you'll need a wheel that has a 5 on 5.5" bolt pattern with a 4.25" center-bore for 5/8" wheel studs.
This kit is for the serious racer and requires extensive fabrication. We recommend a qualified off-road race shop to install and setup this suspension system.
What's Included:
- Boxed lower arms
- Tubular heim upper arms
- Full heim steering
- Fabricated spindles
- Camburg 2.25 billet front hubs (5 on 5.5" bolt pattern)
- Wilwood 12" x 1.25" vented rotors
- Wilwood forged superlite 4 piston calipers w/ BP-20 pads
- All heims, Uniballs and hardware required
- Lift: 4-6 in
- Wheel Travel: 16-18in
- Track Width: +5 in per side
- Wheel Size: 15-17 in
- Max Backspacing: 4.75 inch
- Tire Size: 33-37 in
- Ford Ranger XLT 2wd 1998-2012
- This kit is for the serious racer and requires extensive fabrication. We recommend a qualified off-road race shop to install and setup this suspension system.
- Coilovers, Bump stops & Bypass shocks are not included
