BDS Suspension 19-ON Ford Ranger front coilover PS 2.0 IFP 4.5in. 0-3in. Lift - FOX98502133
Upgrade the on-road comfort and off-road control of your 2019-2023 Ford Ranger to FOX Performance Series 2.0 Coil-Over IFP (internal floating piston) shocks. The mono-tube design's internal reservoir separates the shock oil from the high-pressure nitrogen-charged gas chamber. The IFP eliminates oil aeration allowing maximum performance from the factory-tuned precision valving.Locking spring preload rings that allow easy ride height and preload adjustment retain a top-quality racing coil selected to deliver the optimal spring rate. FOX shocks bolt on with no modifications and are designed to level your truck front-to-rear. The metal impact-extruded aluminum body increases cooling capacity and resists rust. Vehicle-specific upper mount includes a composite bushing that isolates noise and vibration.19-ON Ford Ranger front coilover PS 2.0 IFP 4.5in. 0-3in. Lift


  • 2-inch Impact extruded and CNC machined 6061-T6 clear anodized aluminum one-piece body resists rust over time
  • 5/8-inch hard chrome plated heat-treated alloy steel shaft
  • Race-developed high-flow piston design
  • Application-specific valving to maximize performance
  • Internal IFP mono-tube reservoir design


  • Adjustable: Yes
  • Compressed Length: 15.0000
  • Cylinder Diameter: 2
  • Cylinder Material: Aluminum
  • Extended Length: 19.3900
  • Gas Charged: Yes
  • Installation Time: 2-3 Hrs
  • Lower Mount Code: TM
  • Lower Mount Type: Bar Pin
  • Prop 65 (C| R or CR): CR
  • Prop 65 Short Label: WARNING: Cancer and Reproductive Harm - https://www.p65warnings.ca.gov
  • Prop 65 Warning Label: p65.jpg
  • Prop 65 Yes/No: Yes
  • Pvg Product Status: Active
  • Shaft Diameter: 5_8
  • Shaft Material: Chrome Plated Steel
  • Shocks Included: No
  • Title: FOX 2.0 Coil-Over IFP Shock - 0-3 Inch Lift - Performance Series - Ford Ranger (19-23)
  • Travel Length: 4.3900
  • Type: Coil Over
  • Upper Mount Code: OEM
  • Upper Mount Type: TM
Proposition 65

⚠ WARNING: Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov

Vehicle
2019-2023
 Ford Ranger
